Elevation Cluster Dataset Covering Yalu River Basin


LIU Chuang1SHI Ruixiang1HAO Mengmeng1,2
1Institute of Geographic Sciences and Natural Resources Research,Chinese Academy of Sciences,Beijing 100101,China2University of Chinese Academy of Sciences,Beijing 100049,China

DOI:10.3974/geodb.2017.04.20.V1

Published:Nov. 2017

Visitors:437       Data Files Downloaded:51
Data Downloaded:102.55 MB      Citations:

Key Words:

Yalu River Basin,DEM,elevation cluster,Mt. Changbai

Abstract:

The Yalu River rises in southern slope of Tianchi Lake of Mt. Changbai at 2745m and meets the Yellow Sea at the West Korea Bay at 0 m. The total area of the Yalu River basin is 65215.49 km². Based on the DEM data, 8 elevation Clusters were identified and calculated. The statistic results of elevation clusters are: area, which elevation is less than 50m, is 1926.22 km²,2.95% of the total area;the area, which elevation is between 50-100m, is1327.35 km², 2.04% of the total area;the area, which elevation is between 100-200m, is 3141.77 km², 4.82% of the total area;the area, which elevation is between 200-500m, is 15987.50 km², 24.51% of the total area;the area, which elevation is between 500-1000m, is 23492.12 km², 36.02% of the total area;the area, which elevation is between 1000-1500m, is 13868.31 km², 21.27% of the total area;the area, which elevation is between 1500-2000m, is 5102.53 km², 7.82% of the total area;the area, which elevation is higher than 2000m, is 369.69 km², 0.57% of the total area. That means more than 80% of the land in Yalu River Basin is located at 200-1500m; while, only 5% of the land is lower than 100m. The dataset is archived in.adf data format with the data size of 3.72 MB (2 MB in compress).

Foundation Item:

Institute of Geographic Sciences and Natural Resources Research, Chinese Academy of Sciences (11852701YZ)

Data Citation:

LIU Chuang,SHI Ruixiang,HAO Mengmeng.Elevation Cluster Dataset Covering Yalu River Basin[DB/OL].Global Change Research Data Publishing & Repository,2017.DOI:10.3974/geodb.2017.04.20.V1.

Data Product:

ID Data Name Data Size Operation
1 YaluBasinEVC.rar 2058.96kb DownLoad
